KOBA | World Best of Shock Absorbers & Hydrostatic Buffer

제품
Visco Elastic Buffer
카테고리 4단계

카테고리 4단계

Product Category

Series

Series

KVD Series

Model

Model	Stroke(mm)	Max. Energy/Cycle(kJ)	Max. Dynamic Force(kN)	Preload(kN)
KVD55-50	50	3	76	4
KVD100-50	50	9	236	23
KVD100-100	100	18	236	23
KVD130-100	100	33	421	40
KVD130-150	150	50	421	40
KVD180-100	100	51	643	88
KVD180-200	200	102	643	88
KVD180-300	300	154	643	88

KVD Series

Elasto-Fluid Heavy Duty Buffer

KVD Series

Elasto-Fluid Heavy Duty Buffer
Body Thread Size : 55, 100, 130, 180
Stroke : 50, 100, 150, 200, 300

inquiry

Installation Size

Image	Model	Stroke (mm)	Max. Energy/Cycle(kJ)	Max. Dynamic Force(kN)	Preload(kN)
	KVD55-50	50	3	76	4
	KVD100-50	50	9	236	23
	KVD100-100	100	18	236	23
	KVD130-100	100	33	421	40
	KVD130-150	150	50	421	40
	KVD180-100	100	51	643	88
	KVD180-200	200	102	643	88
	KVD180-300	300	154	643	88
