Product Category

Series

Series

Model

Model Stroke
(mm)		 Max.Energy/
Cycle(KJ)ET		 Max.Energy/
Hour(KJ/h)EtC		 Max.Buffer
Force(kN)Fs
KCSC90-50 50 5 251 130
KCSC90-100 100 10 514 130
KCSC90-150 150 16 764 130
KCSC90-200 200 21 1,019 130
KCSC90-250 250 26 1,091 130
KCSC90-300 300 31 1,222 130
KCSC90-350 350 36 1,645 130
KCSC90-400 400 42 1,495 130
KCSC90-450 450 48 1,417 133
KCSC90-500 500 52 1,378 131
KCSC90-600 600 59 1,144 122
KCSC90-700 700 66 793 118
KCSC90-800 800 75 701 118

KCSC 90 Series

KCSC Series Stacker Crane Buffer

KCSC 90 Series

Hydraulic Gas & Oil Stacker Crane Adjustable Buffer
Body Thread Size : 90
Stroke : 50, 100, 150, 200, 250, 300
inquiry

Installation Size

Image Model Stroke
(mm)		 Max.Energy/
Cycle(KJ)ET		 Max.Energy/
Hour(KJ/hr)EtC		 Max.Buffer
Force(kN)Fs
KCSC90-50 50 5 251 130
KCSC90-100 100 10 514 130
KCSC90-150 150 16 764 130
KCSC90-200 200 21 1,019 130
KCSC90-250 250 26 1,091 130
KCSC90-300 300 31 1,222 130
KCSC90-350 350 36 1,645 130
KCSC90-400 400 42 1,495 130
KCSC90-450 450 48 1,417 133
KCSC90-500 500 52 1,378 131
KCSC90-600 600 59 1,144 122
KCSC90-700 700 66 793 118
KCSC90-800 800 75 701 118
