KCSC 200 Series
KCSC Series Stacker Crane Buffer
KCSC 200 Series
Hydraulic Gas & Oil Stacker Crane Adjustable Buffer
Body Thread Size : 200
Stroke : 50, 100, 150, 200, 250, 300, 400, 500, 600, 700, 800, 900, 1000, 1200
Body Thread Size : 200
Stroke : 50, 100, 150, 200, 250, 300, 400, 500, 600, 700, 800, 900, 1000, 1200
Installation Size
| Image | Model | Stroke (mm) |
Max.Energy/ Cycle(KJ)ET |
Max.Energy/ Hour(KJ/hr)EtC |
Max.Buffer Force(kN)Fs |
|---|---|---|---|---|---|
 |
KCSC200-50 | 50 | 20 | 1,226 | 504 |
 |
KCSC200-100 | 100 | 40 | 1,994 | 504 |
 |
KCSC200-150 | 150 | 60 | 2,283 | 504 |
 |
KCSC200-200 | 200 | 81 | 2,584 | 504 |
 |
KCSC200-250 | 250 | 101 | 2,873 | 504 |
 |
KCSC200-300 | 300 | 121 | 3,712 | 504 |
 |
KCSC200-400 | 400 | 161 | 4,295 | 504 |
 |
KCSC200-500 | 500 | 202 | 4,885 | 504 |
 |
KCSC200-600 | 600 | 242 | 5,474 | 504 |
 |
KCSC200-700 | 700 | 282 | 6,059 | 504 |
 |
KCSC200-800 | 800 | 322 | 6,648 | 504 |
 |
KCSC200-900 | 900 | 363 | 7,238 | 504 |
 |
KCSC200-1000 | 1,000 | 377 | 7,952 | 471 |
 |
KCSC200-1200 | 1,200 | 429 | 6,396 | 471 |
