Product Category

Series

Series

Model

Model Stroke
(mm)		 Max.Energy/
Cycle(KJ)ET		 Max.Energy/
Hour(KJ/h)EtC		 Max.Buffer
Force(kN)Fs
KCSC110-50 50 8 385 195
KCSC110-100 100 14 738 179
KCSC110-150 150 21 1,145 179
KCSC110-200 200 29 1,214 179
KCSC110-250 250 35 1,373 176
KCSC110-300 300 43 1,543 179
KCSC110-350 350 49 1,758 176
KCSC110-400 400 57 1,972 179
KCSC110-450 450 64 2,184 177
KCSC110-500 500 72 2,399 179
KCSC110-600 600 86 2,818 179
KCSC110-700 700 99 3,231 176
KCSC110-800 800 108 3,648 169
KCSC110-900 900 114 4,069 159
KCSC110-1000 1,000 117 4,528 146
KCSC110-1200 1,200 125 3,585 130
KCSC110-1400 1,400 135 2,492 121

KCSC 110 Series

KCSC Series Stacker Crane Buffer

KCSC 110 Series

Hydraulic Gas & Oil Stacker Crane Adjustable Buffer
Body Thread Size : 110
Stroke : 50, 100, 150, 200, 250, 300
inquiry

Installation Size

Image Model Stroke
(mm)		 Max.Energy/
Cycle(KJ)ET		 Max.Energy/
Hour(KJ/hr)EtC		 Max.Buffer
Force(kN)Fs
KCSC110-50 50 8 385 195
KCSC110-100 100 14 738 179
KCSC110-150 150 21 1,145 179
KCSC110-200 200 29 1,214 179
KCSC110-250 250 35 1,373 176
KCSC110-300 300 43 1,543 179
KCSC110-350 350 49 1,758 176
KCSC110-400 400 57 1,972 179
KCSC110-450 450 64 2,184 177
KCSC110-500 500 72 2,399 179
KCSC110-600 600 86 2,818 179
KCSC110-700 700 99 3,231 176
KCSC110-800 800 108 3,648 169
KCSC110-900 900 114 4,069 159
KCSC110-1000 1,000 117 4,528 146
KCSC110-1200 1,200 125 3,585 130
KCSC110-1400 1,400 135 2,492 121
