KCSC 275 Series
KCSC Series Stacker Crane Buffer
KCSC 275 Series
Hydraulic Gas & Oil Stacker Crane Adjustable Buffer
Body Thread Size : 275
Stroke : 100, 150, 200, 250, 300, 400, 500, 600, 750, 900, 1050, 1200
Body Thread Size : 275
Stroke : 100, 150, 200, 250, 300, 400, 500, 600, 750, 900, 1050, 1200
Installation Size
| Image | Model | Stroke (mm) |
Max.Energy/ Cycle(KJ)ET |
Max.Energy/ Hour(KJ/hr)EtC |
Max.Buffer Force(kN)Fs |
|---|---|---|---|---|---|
 |
KCSC275-100 | 100 | 101 | 3,179 | 1,268 |
 |
KCSC275-150 | 150 | 152 | 3,596 | 1,268 |
 |
KCSC275-200 | 200 | 203 | 3,969 | 1,268 |
 |
KCSC275-250 | 250 | 252 | 4,385 | 1,261 |
 |
KCSC275-300 | 300 | 303 | 4,897 | 1,262 |
 |
KCSC275-400 | 400 | 404 | 5,594 | 1,263 |
 |
KCSC275-500 | 500 | 506 | 6,414 | 1,264 |
 |
KCSC275-600 | 600 | 607 | 8,042 | 1,265 |
 |
KCSC275-750 | 750 | 758 | 9,252 | 1,263 |
 |
KCSC275-900 | 900 | 910 | 10,462 | 1,264 |
 |
KCSC275-1050 | 1,050 | 1,061 | 11,661 | 1,263 |
 |
KCSC275-1200 | 1,200 | 1,027 | 10,479 | 1,070 |
