KHAT 64 Series
KHA Heavy type Absorber
KHAT 64 Series
Heavy type Absorber
Body Thread Size : 64
Stroke : 50, 100, 150
Body Thread Size : 64
Stroke : 50, 100, 150
Installation Size
| Image | Model | Stroke (mm) |
Max.Energy/ Cycle(Nm)ET |
Max.Energy/ Hour(Nm/h)EtC |
Effctive Weight(kg) |
M |
|---|---|---|---|---|---|---|
 |
KHAT64-50 | 50 | 2,260 | 270,000 | 370 - 50,000 | M64X2.0P |
 |
KHAT64-50LV | 50 | 2,260 | 270,000 | 2,480 - 706,000 | M64X2.0P |
 |
KHAT64-100 | 100 | 4,250 | 360,000 | 700 - 94,000 | M64X2.0P |
 |
KHAT64-150 | 150 | 6,780 | 420,000 | 1,100 - 151,000 | M64X2.0P |
